Excel

In this example we will demonstrate: Connecting to RFEM and creating new model Extracting data from Excel sheet Saving new data to Excel sheet Read the comments for detailed instructions.

import os
import xlwings as xw
from dlubal.api import rfem

def open_work_book():
    """Open excel file."""

    dirname = os.path.join(os.getcwd(), os.path.dirname(__file__))
    path = os.path.join(dirname,'src/Nodes.xlsx')

    wb = xw.Book(path)

    return wb

def close_work_book(wb):
    """Close excel file."""

    wb.save()
    app = wb.app
    wb.close()
    app.kill()

def get_node_from_excel(work_book) -> dict:
    """Retrieve node from excel file."""

    input_sheet = work_book.sheets('Nodes')

    node1 = {'no' : int(input_sheet["A2"].value),
              'x' : input_sheet["B2"].value,
              'y' : input_sheet["C2"].value,
              'z' : input_sheet["D2"].value}

    return node1

def write_node_to_excel(node, work_book) -> None:
    """Write data to excel file."""

    input_sheet = work_book.sheets('Nodes')

    input_sheet["A3"].value = node.no
    input_sheet["B3"].value = node.coordinate_1
    input_sheet["C3"].value = node.coordinate_2
    input_sheet["D3"].value = node.coordinate_3
    if node.comment:
        input_sheet["E3"].value = node.comment


if __name__ == "__main__":
    """Main routine."""

    with rfem.Application() as rfem_app:

        # Step 1: Create a new model
        rfem_app.close_all_models(save_changes=False)
        rfem_app.create_model(name='excel')

        # Step 2: Clear existing objects
        rfem_app.delete_all_objects()

        # Step 3: Get data for node from excel
        work_book = open_work_book()

        # Step 4: Create nodes in RFEM
        node1 = get_node_from_excel(work_book)

        rfem_app.create_object_list(objs = [
            rfem.structure_core.Node(
                no = node1['no'],
                coordinate_1 = node1['x'],
                coordinate_2 = node1['y'],
                coordinate_3 = node1['z']),
            rfem.structure_core.Node(
                no = 2,
                coordinate_1 = 1,
                coordinate_2 = 2,
                coordinate_3 = 4,
                comment = 'Node 2')])

        # Step 4: Get node 2 from RFEM
        node2 = rfem_app.get_object(
            obj = rfem.structure_core.Node(
                no = 2))
        write_node_to_excel(node2, work_book)

        # Step 5: Save and close excel file
        close_work_book(work_book)
